Molecular sieve oxygen generator comprehensive analysis

Molecular sieve oxygen generator comprehensive analysis

The molecular sieve oxygen generator generally adopts a pressurized adsorption atmospheric pressure desorption (HP) method, and the same cycle process is carried out by two adsorption towers respectively, thereby realizing continuous gas supply. The entire system is completely controlled by the microcontroller.

Classification of molecular sieve oxygen generators: household molecular sieve oxygen generators and medical molecular sieve gas generators.

The working principle of the molecular sieve oxygen generator:

This process is two towers. After the raw material air is pressurized by the compressor, solid impurities such as oil, dust, and water are removed by an air pretreatment apparatus, and cooled to normal temperature. The treated compressed air enters the adsorption column containing the molecular sieve through the intake valve in the air. Nitrogen and carbon dioxide are adsorbed, and the gas flowing out is high-purity oxygen. When the adsorption tower reaches a certain saturation, the intake valve is closed, the flush valve is opened, and the adsorption tower enters the flushing phase. After that, close the flush valve and open the desorption valve. Enter the desorption regeneration phase and complete a cycle.

Main technical parameters of molecular sieve oxygen generator:

1. the device is in normal working condition

   Ambient temperature: 5 ° C ~ 40 ° C

   Power supply voltage: oxygen generator 220V ± 22V air compressor, oxygen compressor       380V ± 38V

   Power frequency: 50Hz±1Hz

   Power: 37KW

   Relative humidity: ≤80%

   Atmospheric pressure: 86Kpa~106Kpa

   Host size L × W × H (no air compressor): 3.5 m × 1.8 m × 2.7 m

2. Physical and chemical indicators of oxygen produced by the equipment

   Oxygen production 20m3 / h

   Oxygen concentration: ≥90% (V / V)

   Moisture content: ≤0.07g/ m3

   Carbon dioxide content: ≤0.01% (V / V)

   Carbon monoxide content should be in accordance with YY / T0298

   The content of gaseous acid and alkali should meet the requirements of YY / T0298

   Ozone and other gaseous oxides shall comply with the requirements of YY / T0298

   Solid material particle size: ≤10μm

   Solid content: ≤0.5mg/ m3

Advantages of molecular sieve oxygen generators:

Advanced principle: Separation of oxygen and nitrogen in the air by zeolite molecular sieve and pressure swing adsorption (PSA) to filter out harmful substances in the air to obtain high-purity oxygen in line with medical oxygen standards.

Low oxygen production costs: air as raw material, no additives, no residual pollution, low power consumption. Easy to use: the plug produces oxygen, the operation is simple, the oxygen concentration is stable, the oxygen flow is adjustable, and it can be used continuously for 24 hours.

Safe and reliable: complete gas routing low-voltage system program control, stable performance, low noise.
