Chemical molecular formula:mSiO2.nAl2O3.XH2O.
Chemically stable,flame-resisting.Insoluble in any solvent except strong alkali or hydroelectric acid. In comparison with fine-pored silica gel ,the adsorption capacity of HY-H silica alumina gel is quite the same when used at low relative humidity ,(e.g.RH=10%,RH=20%),while its adsorption capacity at high humidity is 6—10%higher than that of fine-ported silica gel. Its thermal stability is over 150℃ higher than that of fine-pored silica gel (200 ℃).Ideally suited for use as absorbent and variable-temperature absorbent.
XINTAO Alumina Silica Gel WS Type
Chemical molecular formula:mSiO2.nAl2O3.XH2O.
This product is a water-resistant silica-alumina gel with a high adsorbent capacity．It is usually used as protective layer in combination with silica gel H type, molecular sieve, and can be used solely when free water (liquid water carry over) is in high content.
Application
It is mainly used as drying agent for air-separation, compressed air dryers and industrial gases, Natural gas dryers for controlling water dew point. It is recommended a layer about 10-20%(wt) should be consider as protective layer in order to increase the reliability of the system.
Technical Data
| Items | Specifications | |
| SiO2 | % | 85 min |
| Al2O3 | % | 15 max |
| Particle Size | mm | 2.0-5.0 |
| Surface Area | ㎡/g | ≥500 |
Adsorption capacity（25℃，wt％） | RH10% | ≥3.5 |
| RH20% | ≥6.0 | |
| RH60% | ≥22.0 | |
| RH80% | ≥32.0 | |
| Bulk density | g/l | ≥680 |
| Crushing strength | N | ≥80 |
| Attrition Loss | wt% | ≤0.05 |
| Pore volume | c㎡/g | 0.35-0.45 |
| Moisture content | wt％ | ≤3.0 |
